INCH-POUND
MIL-DTL-81969/39B
28 March 2008
SUPERSEDING
MIL-I-81969/39A
28 August 1985
DETAIL SPECIFICATION SHEET
INSTALLING AND REMOVAL TOOL, CONNECTOR ELECTRICAL CONTACTS,
TYPE III, CLASS 2, COMPOSITION B
This specification sheet is approved for use by all Departments and Agencies of the Department
of Defense.
The requirements for acquiring the product described herein shall consist of this specification
sheet and MIL-I-81969.
4.50
3.50
.100
.100
INSERTION SIDE
REMOVAL SIDE
MIN.
MIN.
(GREEN)
(WHITE)
.105
.105
REMOVAL
.350 MAX SQ.
INSERTION
.075
.075
.028
.030
SIDE SLIT
BOTH SIDES
SIDE SLIT
.020
.020
SEE REQUIREMENT 8
.260
SEE REQUIREMENT 8
1.230
1.230
MAX.
1.180
1.180
BODY DESIGN
.380
.380
OPTIONAL
.280
.280
MIL NUMBER
.045
.260
& MFG NAME
.020
MAX.
LOCATION OPTIONAL
.200
.115
SEE
SEE
.069
REQUIRE- .069 DIA.
DIA. REQUIRE-
.068
.068
MENT 9
MENT 9
.0085
.0085
.0075
.0075
FIGURE 1. Installing and removal tool.
AMSC N/A
FSC 5120
